EC 6025 Cooling fan 110V 220V

EC Axial Fan 6025 (60×60×25 mm): 115/230 VAC, up to 25.2 CFM, CE & RoHS. OEM/ODM wholesale from YUNFAN.

Category: Brand:

EC 6025 Cooling fan 110V 220V

Applicable Industry servers,ozone machine,air conditioner,Telecom,industrial,Automotive,consumer,information technology
Bearing type double ball bearing type
Brand Name YUNFANPOWER
Keyword ec fan,ec axial fan,waterproof fan,high speed cooling fan
Model Number EC 6025
Voltage support 115/230 VAC
Warranty 2years
Weight 54g

Shenzhen Yunfan Power Co.LimitedShenzhen Yunfan Power Co.Limited Shenzhen Yunfan Power Co.Limited Shenzhen Yunfan Power Co.Limited Shenzhen Yunfan Power Co.Limited Shenzhen Yunfan Power Co.Limited Shenzhen Yunfan Power Co.Limited Shenzhen Yunfan Power Co.Limited

FAQ:

Q1: How long are you doing fan business ?

A1:
More than 8years do fan business.

Q2: What is DC Fan and AC fan?

A2:
DC fan is power by DC voltage,always is 5V 12V 24V 48V 60V and 72V.
AC fan is power by AC voltage,always is 110V,220V and 380V.

Q3: How to choose DC fan?

A3:
1 size of the fan samples:6025 (60*60*25mm)
2 Voltage 5V/12V/24V/48V
3 current 0.17A
4 speed 5000RPM
5 air flow 25CFM
6 noise 40dBA
7 bearing type:choose ball bearing type or sleeve bearing type ?
8 two wire or three wire 2wire
9 cable length 300mm
10 connector molex 2510 or no connector
11 function FGRDPWMSoft Start ......

Q4: What is the delivery time?

A4:
Sample lead time:5-10 days
Mass production Delivery lead time: 1 -3 weeks(Depend on the  quantity)

Q5: Can you tell me the normal DC fan Model?

A5:
40*40*10mm 40*40*20mm 40*40*28mm
50*50*10mm 50*50*15mm 50*50*20mm 60*60*10mm 60*60*15mm 60*60*25mm
80*80*25mm 80*80*38mm 92*92*25mm 92*92*38mm
120*120*25mm 120*120*32mm  120*120*38mm  140*140*38mm  140*140*50mm
150*150*50mm 172*150*51mm  180*180*60mm  225*225*80mm  280*280*80mm

EC Axial Fan 6025 (60×60×25 mm) — Series Overview

The EC Axial Fan 6025 is a 60×60×25 mm energy-efficient EC axial cooling fan series from Shenzhen Yunfan Power. It operates on 115/230 VAC with ball / sleeve bearing options, running 3000–5500 RPM and delivering up to 25.2 CFM with noise levels from 24 dBA. With up to 50% energy savings over equivalent AC fans and wide-voltage EC drives, it is ideal for data centers, telecom, refrigeration and green building HVAC. Wholesale pricing and OEM customization are supported.

Key Features

  • Energy-saving EC motor — Electronically commutated drive cuts power draw by up to 50% versus equivalent AC fans.
  • Wide-voltage input — Operates across 98–264 VAC (115/230V rated) for global deployment without rewiring.
  • Bearing options for every duty — Sleeve bearing for cost-sensitive builds; ball bearing for long-life 24/7 and any-angle mounting.
  • Certified and procurement-ready — CE certified and RoHS compliant; certificates available with shipment.
  • OEM / ODM customization — Custom voltage, speed, connectors, lead wires and private labeling from low MOQ.

Applications of the YUNFAN EC Axial Fan Series

  • Data centers & servers — High-efficiency rack and node cooling with lower PUE and energy cost.
  • Telecom base stations & rectifiers — Wide-voltage EC cooling for outdoor cabinets and shelters.
  • Commercial refrigeration — Condenser and evaporator fans with stepless EC speed control.
  • HVAC & fresh-air systems — Energy-saving airflow for AHUs, ERVs and ceiling ventilation.
  • Green buildings & Heat pumps — Low-noise, high-efficiency fans for LEED/BREEAM projects.

Technical Specifications — Standard Datasheet

Full model list of the 6025 series (60x60x25mm), 3 part numbers:

ModelBearing (Ball / Sleeve)Rated Voltage (VAC)Freq (Hz)Operation Voltage (VAC)Rated Current (A)Power (W)Rated Speed (RPM)Air Flow (CFM)Air Pressure (mmH₂O)Noise Level (dBA)Weight (g)
YF6025HB/SL/150/230EBall / Sleeve115/23050/6098–2640.054.0550025.26.53762
YF6025MB/SL/150/230EBall / Sleeve115/23050/6098–2640.043.0400018.34.23062
YF6025LB/SL/150/230EBall / Sleeve115/23050/6098–2640.032.0300013.62.32462

Frequently Asked Questions — EC Axial Fan 6025

Why choose an EC fan over an AC fan?

EC fans use electronically commutated motors that cut energy use by up to 50%, run cooler, support speed control and offer a wide 98–264 VAC input — ideal for 24/7 and energy-regulated applications.

What is the difference between sleeve and ball bearing versions?

Sleeve bearing is the most cost-effective and quietest option, best for horizontal mounting. Ball bearing lasts longer, tolerates any mounting angle and higher ambient temperature — recommended for 24/7 duty.

Can I order the 6025 with custom speed, connector or function options?

Yes. Custom RPM, voltage, lead connectors and function options (FG/RD signal, PWM/TC speed control, AS auto restart) are available. MOQ starts from 100 pieces and samples are supported for testing.

What is your lead time and warranty?

Standard models ship in 7–15 days; custom orders in 20–30 days. All fans carry a 2-year warranty with lifetime technical support.
